Teerasil Fittings and Plates, Bangkok, Thailand, is a prominent producer and distributor of **Stainless Steel 317/317L forged fittings** for piping systems that require superior performance. The forged fittings have superior resistance to chemical attack as well as corrosion, particularly in sulfur and chloride-containing environments. Stainless Steel 317 has greater strength as well as corrosion resistance, whereas 317L, the low-carbon version, offers excellent weldability as well as resistance to intergranular corrosion. Teerasil produces these fittings according to international standards such as ASTM A182, meeting the needs of chemical processing, pulp and paper, marine, and pharmaceutical industries with efficient, durable components.
Specifications : ASTM A182 / ASME SA182
Dimensions : ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
Stainless Steel 317/317L forged fittings are produced using austenitic stainless steel with 18–20% chromium, 11–15% nickel, and 3–4% molybdenum. The additional molybdenum gives improved resistance to crevice corrosion and pitting in harsh environments. Grade 317L contains a maximum of 0.03% carbon, reducing the chances of carbide precipitation upon welding. These fittings provide tensile strength of approximately 515 MPa and yield strength of about 205 MPa. The forging operation enhances their mechanical strength, pressure-handling capacity, and grain structure even more, making them best suited for critical and corrosive applications.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Teerasil Fittings is a leading supplier of Stainless Steel 317/317L Forged Fittings in Bangkok, Thailand. We offer an extensive range of Stainless Steel 317/317L Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | – |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
Choose Stainless Steel 317/317L Forged Fittings from Teerasil Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Stainless steel 317/317L forged fittings provide excellent corrosion resistance, especially in high chloride environments, making them ideal for chemical, petrochemical, and marine applications These alloys have excellent strength and thermal stability even at higher levels, providing longer service life. The low carbon content of 317L reduces carbide precipitation, increases weldability and reduces the susceptibility to stress corrosion cracking. In addition, they are more resistant to oxidation and pitting, increasing the longevity of the systems. Their high resistance to sulfuric and hydrochloric acids makes them suitable for aggressive chemical applications.
Yes, custom sizes for Stainless Steel 317/317L Forged Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com
| Fitting Schedule/Class | Pipe Size – Pipe Fitting | Fitting Connection Type | Pipe Fitting Material | Max. Pressure |
|---|---|---|---|---|
| Class 150 | 1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1/2″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 1/2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 3/4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 3/4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 3/4″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 3/4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 3/4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 1″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/4″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 1-1/4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/2″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 1-1/2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 1-1/2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 2″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 2-1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 2-1/2″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 2-1/2″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 2-1/2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 2-1/2″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 3″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 3″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 3″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 3″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 4″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 4″ | Forged | Forged Stainless Steel 317 | 275 psi |
| Class 150 | 4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 4″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 6″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 6″ | FNPT | Stainless Steel 317 | 150 psi |
| Class 150 | 6″ | Welded | Stainless Steel 317 | 150 psi |
| Class 150 | 6″ | Welded | Stainless Steel 317 | 150 psi |
| DN-NPT | MAJOR DIAMETER MM | TAPPING DRILL SIZE MM | TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
Stainless Steel 317/317L forged fittings find extensive application where corrosion resistance and mechanical strength are prerequisites. In petrochemical and chemical plants, they manage acidic, chlorinated, and high-temperature media. The pulp and paper industry utilizes them in bleaching systems and chemical recovery lines. Marine applications are aided by their saltwater corrosion resistance. They are also utilized in pharmaceutical and food processing systems where material integrity and cleanliness are important. These forged fittings guarantee leak-free connections, life, and best performance in demanding and extreme service conditions.
