Teerasil Fittings is a trusted manufacturer and supplier of Carbon Steel P235GH Pipe Fittings in Bangkok, Thailand. Our high-quality P235GH fittings are designed for use in various industrial applications, offering excellent weldability, durability, and resistance to pressure and temperature. These fittings are ideal for the power, oil and gas, and construction industries, providing reliability and performance in demanding environments. We specialize in delivering custom solutions tailored to meet the specific requirements of each project, ensuring superior quality and customer satisfaction in every product.
| Size Range | Welded Fittings: 1/2″ – 48″ Seamless Fittings: 1/2″ – 10″ |
|---|---|
| Bending Radius | R=8D, 3D, 10D, 1D, 2D, 5D, 6D or Custom MSS Sp-43 |
| Elbows | Angle : 3D, 4D, 5D, 6D, 1.0D, 1.5D, 2.0D, 2.5D, 7D-40D . Standard: MSS SP-75 JISB2312 JISB2313, ASME B16.9, 22.5 deg, 30deg, 45 deg, 90 deg, DIN2605 JISB2311 BS, 180 deg, GB, ISO |
| Specialized manufacturer of | 90º Elbows, Tee, Stub End, Pipe Cap, Crosses, 45º Elbows, Reducers, Pipe Bend |
| Thickness | SCH 140, SCH 160, SCH10, SCH30, STD SCH40, SCH20, XS, SCH 80, SCH60, SCH 100, SCH 120, XXS |
| Dimensions | ASME/ANSI B16.9, BS4504, ASME B16.28, MSS-SP-43, BS4504, BS1560, BS10 |
| Manufacturing process | Press, Forge, Push, Cast, etc. |
| Origin & Mills | Japanese, Korean, European, Indian, USA, Ukraine, Russian |
| Type | DN15-DN1200 |
| Connection | Welding |
| Test Certificates | Raw Materials Certificate EN 10204/3.1B Third Party Inspection Report, etc |
Carbon Steel P235GH pipe fittings are primarily composed of carbon, silicon, manganese, and small amounts of other elements like phosphorus and sulfur. The material has excellent weldability, making it suitable for high-temperature applications. Its chemical composition typically includes 0.17-0.20% carbon, 0.30-0.60% manganese, and 0.030% sulfur. Mechanically, it exhibits good strength, with a yield strength of around 235 MPa and tensile strength of up to 360 MPa. The material also offers good formability, ensuring durability and reliability in applications requiring pressure resistance and temperature tolerance.
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | Cu | – |
| max 0.16 | max 0.35 | 0.6 – 1.2 | max 0.3 | max 0.025 | max 0.015 | max 0.3 | max 0.08 | max 0.02 | max 0.012 | max 0.02 | max 0.03 | max 0.02 | max 0.3 | Cr+Cu+Mo+Ni < 0.7 |
| Nominal thickness (mm): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 360-480 | 350-480 | 340-480 |
Teerasil Fittings is a leading supplier of Carbon Steel P235GH Pipe Fittings in Bangkok, Thailand. We offer an extensive range of Carbon Steel P235GH Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P235GH Pipe Fittings from Teerasil Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Carbon Steel P235GH pipe fittings offer numerous advantages, including excellent weldability, making them ideal for high-pressure and high-temperature environments. Their strong mechanical properties, such as a yield strength of 235 MPa and tensile strength up to 360 MPa, ensure reliability and durability. These fittings provide excellent corrosion resistance in various industrial applications, ensuring long-lasting performance. Additionally, they are cost-effective compared to other materials, offering a great balance between quality and price. Their versatility allows them to be used in a wide range of industries, including power generation, petrochemical, and HVAC systems.
Yes, custom sizes for Carbon Steel P235GH Pipe Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Belgium NBN | Spain UNE | China GB | Sweden SS | Poland PN | Czechia CSN | Finland SFS | Austria ONORM | Russia GOST | Inter ISO | India IS | |||||||||||||||||||||||||||||||
| P235GH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Reducers | ||
|---|---|---|---|---|
|
Reduced from
(inches) |
(mm) |
(inches) |
Reduced to
(inches) |
Concentric & Eccentric Length
(inches) |
|
1/2 |
21.3 |
0.840 |
1/4 |
1 1/2 |
|
3/8 |
1 1/2 |
|||
|
3/4 |
26.7 |
1.050 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
1 |
33.4 |
1.315 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
3/4 |
2 |
|||
|
1 1/4 |
42.2 |
1.660 |
1/2 |
2 |
|
3/4 |
2 |
|||
|
1 |
2 |
|||
|
1 1/2 |
48.3 |
1.900 |
1/2 |
2 1/2 |
|
3/4 |
2 1/2 |
|||
|
1 |
2 1/2 |
|||
|
1 1/4 |
2 1/2 |
|||
|
2 |
60.3 |
2.375 |
3/4 |
3 |
|
1 |
3 |
|||
|
1 1/4 |
3 |
|||
|
1 1/2 |
3 |
|||
|
2 1/2 |
73.0 |
2.875 |
1 |
3 1/2 |
|
1 1/4 |
3 1/2 |
|||
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
3 |
88.9 |
3.500 |
1 |
3 1/2 |
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
2 1/2 |
3 1/2 |
|||
|
3 1/2 |
101.6 |
4.000 |
1 1/4 |
4 |
|
1 1/2 |
4 |
|||
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
4 |
114.3 |
4.500 |
1 1/2 |
4 |
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
3 1/2 |
4 |
|||
|
5 |
141.3 |
5.563 |
2 |
5 |
|
2 1/2 |
5 |
|||
|
3 |
5 |
|||
|
3 1/2 |
5 |
|||
|
4 |
5 |
|||
|
6 |
168.3 |
6.625 |
2 1/2 |
5 1/2 |
|
3 |
5 1/2 |
|||
|
3 1/2 |
5 1/2 |
|||
|
4 |
5 1/2 |
|||
|
5 |
5 1/2 |
|||
|
8 |
219.1 |
8.625 |
3 |
6 |
|
3 1/2 |
6 |
|||
|
4 |
6 |
|||
|
5 |
6 |
|||
|
6 |
6 |
|||
|
10 |
273.1 |
10.750 |
4 |
7 |
|
5 |
7 |
|||
|
6 |
7 |
|||
|
8 |
7 |
|||
|
12 |
323.9 |
12.750 |
5 |
8 |
|
6 |
8 |
|||
|
8 |
8 |
|||
|
10 |
8 |
|||
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Carbon Steel P235GH pipe fittings are widely used in high-pressure and high-temperature applications, particularly in industries like power generation, petrochemicals, and heating systems. Their excellent weldability and strength make them ideal for steam systems, boilers, and pressure vessels. These fittings are also used in oil and gas pipelines, refineries, and HVAC systems, where they provide reliable performance under demanding conditions. Due to their cost-effectiveness and durability, they are a preferred choice for critical applications where safety, strength, and longevity are essential.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
