ASTM A860 WPHY 65 Pipe Fittings

Teerasil Fittings is a leading manufacturer and supplier of high-quality pipe fittings in Bangkok, Thailand. Specializing in ASTM A860 WPHY 65 Pipe Fittings, we provide reliable solutions for high-pressure and high-strength pipeline systems. Designed to meet stringent industry standards, our fittings offer exceptional durability, corrosion resistance, and excellent performance in extreme conditions. Ideal for industries such as oil, gas, petrochemical, and power generation, Teerasil Fittings ensures secure, long-lasting connections that enhance pipeline integrity and efficiency in critical applications.

ASTM A860 WPHY 65 Pipe Fittings Price List in Bangkok, ASTM A860 WPHY 65 Pipe Fittings Supplier in Chiang Mai, ASTM A860 WPHY 65 Pipe Fittings Exporter in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Supplier in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Exporter in Rayong, ASTM A860 WPHY 65 Pipe Fittings Size Chart, ASTM A860 WPHY 65 Pipe Fittings Price in Nonthaburi, ASTM A860 WPHY 65 Pipe Fittings in Bangkok, ASTM A860 WPHY 65 Pipe Fittings Supplier in Thailand, ASTM A860 WPHY 65 Pipe Fittings Stockist in Chiang Mai, ASTM A860 WPHY 65 Pipe Fittings Exporter in Thailand

ASTM A860 WPHY 65 Pipe Fittings Specification

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 – MSS-SP-75 WPHY 65
Type	Seamless / Welded / Fabricated
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Range	½”NB to 48″NB in Sch 10s, 40s, 80s, 160s, XXS.
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.

ASTM A860 WPHY 65 Pipe Fittings are composed of carbon, manganese, phosphorus, sulfur, and silicon, with additional alloying elements like vanadium, titanium, and niobium to improve strength and durability. These fittings offer exceptional mechanical properties, with a minimum tensile strength of 690 MPa and a minimum yield strength of 485 MPa. They are designed to withstand high-pressure, low-temperature environments, offering excellent impact resistance and corrosion resistance. ASTM A860 WPHY 65 fittings are ideal for critical applications in demanding industries such as oil, gas, petrochemical, and power generation.

ASTM A860 WPHY 65 Pipe Fittings Chemical Compostion

	C	Mn	P	S	Si	Ni	Cr	Mo	Cu	Ti	V	Cb	Al
A860	0.20	1.00-1.45	0.03	0.01	0.15-0.40	0.50	0.30	0.25	0.35	0.05	0.10	0.04	0.06

ASTM A860 WPHY 65 Pipe FittingsMechanical Properties

Mechanical Properties	Tensile (MPa)	Yield (MPa)	Elongation % 2in
WPHY65	530-705	450	28

ASTM A860 WPHY 65 Pipe Fittings Exporter in Thailand, ASTM A860 WPHY 65 Pipe Fittings Price List in Bangkok, ASTM A860 WPHY 65 Pipe Fittings Supplier in Chiang Mai, ASTM A860 WPHY 65 Pipe Fittings Exporter in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Exporter in Rayong, ASTM A860 WPHY 65 Pipe Fittings in Nonthaburi, ASTM A860 WPHY 65 Pipe Fittings Size Chart, ASTM A860 WPHY 65 Pipe Fittings Price in Nonthaburi, ASTM A860 WPHY 65 Pipe Fittings Weight Chart, ASTM A860 WPHY 65 Pipe Fittings Supplier in Thailand, ASTM A860 WPHY 65 Pipe Fittings Stockist in Chiang Mai

Largest ASTM A860 WPHY 65 Pipe Fittings Supplier in Bangkok, Thailand

Teerasil Fittings is a leading supplier of ASTM A860 WPHY 65 Pipe Fittings in Bangkok, Thailand. We offer an extensive range of ASTM A860 WPHY 65 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose ASTM A860 WPHY 65 Pipe Fittings from Teerasil Fittings?

Choose ASTM A860 WPHY 65 Pipe Fittings from Teerasil Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

ASTM A860 WPHY 65 Pipe Fittings Exporter in Chiang Mai, ASTM A860 WPHY 65 Pipe Fittings Sizes in mm, ASTM A860 WPHY 65 Pipe Fittings Manufacturer in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Thickne Alloy Steel Weld Neck, ASTM A860 WPHY 65 Pipe Fittings Supplier in Bangkok, ASTM A860 WPHY 65 Pipe Fittings Price List in Thailand, ASTM A860 WPHY 65 Pipe Fittings Distributor in Rayong, ASTM A860 WPHY 65 Pipe Fittings Supplier in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Distributor in Thailand

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

ASTM A860 WPHY 65 Pipe Fittings provide numerous advantages, including exceptional strength and durability, making them ideal for high-pressure and high-stress applications. With a tensile strength of 690 MPa and yield strength of 485 MPa, they offer superior resistance to corrosion, impact, and stress, ensuring reliable performance in harsh environments. These fittings are particularly well-suited for low-temperature and offshore applications, providing secure, leak-proof connections. Their high mechanical properties reduce maintenance needs and extend service life, making them a cost-effective choice for critical pipeline systems in industries like oil, gas, and petrochemicals.

Types of ASTM A860 WPHY 65 Pipe Fittings

Are Custom Sizes Available for ASTM A860 WPHY 65 Pipe Fittings?

Yes, custom sizes for ASTM A860 WPHY 65 Pipe Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com

ASTM A860 WPHY 65 Pipe Fittings Dimensions

Nominal Pipe Size	Outside Diameter		Caps	Straight Tees	Straight Crosses	Stub Ends
inch	mm	inch	Length (inch)	Center to End (inch)	Center to End (inch)	Lap Diameter (inch)	Long Length (inch)	Short Length (inch)
1/2	21.3	0.840	1	1	–	1 3/8	3	2
3/4	26.7	1.050	1	1 1/8	–	1 11/16	3	2
1	33.4	1.315	1 1/2	1 1/2	1 1/2	2	4	2
1 1/4	42.2	1.660	1 1/2	1 7/8	1 7/8	2 1/2	4	2
1 1/2	48.3	1.900	1 1/2	2 1/4	2 1/4	2 7/8	4	2
2	60.3	2.375	1 1/2	2 1/2	2 1/2	3 5/8	6	2 1/2
2 1/2	73.0	2.875	1 1/2	3	3	4 1/8	6	2 1/2
3	88.9	3.500	2	3 3/8	3 3/8	5	6	2 1/2
3 1/2	101.6	4.000	2 1/2	3 3/4	3 3/4	5 1/2	6	3
4	114.3	4.500	2 1/2	4 1/8	4 1/8	6 3/16	6	3
5	141.3	5.563	3	4 7/8	4 7/8	7 5/16	8	3
6	168.3	6.625	3 1/2	5 5/8	5 5/8	8 1/2	8	3 1/2
8	219.1	8.625	4	7	7	10 5/8	8	4
10	273.1	10.750	5	8 1/2	8 1/2	12 3/4	10	5
12	323.9	12.750	6	10	10	15	10	6

ASTM A860 WPHY 65 Pipe Fittings Weight Chart

DN	Schedule 10S			Schedule 40S			Schedule 80S
900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee	900 Elbow	450 Elbow	Equal tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

ASTM A860 WPHY 65 Pipe Fittings Supplier in Bangkok, ASTM A860 WPHY 65 Pipe Fittings Weight Chart, ASTM A860 WPHY 65 Pipe Fittings Exporter in Chiang Mai, ASTM A860 WPHY 65 Pipe Fittings Manufacturer in Pattaya, ASTM A860 WPHY 65 Pipe Fittings Price List in Thailand, ASTM A860 WPHY 65 Pipe Fittings Sizes in mm, ASTM A860 WPHY 65 Pipe Fittings Distributor in Rayong, ASTM A860 WPHY 65 Pipe Fittings in Nonthaburi, ASTM A860 WPHY 65 Pipe Fittings Distributor in Thailand

Application Industry of ASTM A860 WPHY 65 Pipe Fittings

ASTM A860 WPHY 65 Pipe Fittings are widely used in industries requiring high-strength and durable pipeline systems. These fittings are essential for oil and gas transportation, petrochemical processing, and power generation, particularly in high-pressure and low-temperature environments. They are also applied in offshore drilling, water treatment plants, and chemical processing facilities where secure, corrosion-resistant connections are critical. ASTM A860 WPHY 65 fittings ensure long-term performance in demanding conditions, making them ideal for critical applications where pipeline integrity and reliability are paramount.
