Inconel 600 Buttweld Fittings

Teerasil Fittings and Plates is a top-notch manufacturer and supplier located in Thailand, Bangkok, specializing in high-quality Inconel 600 Buttweld Fittings. These fittings are essential for industries that demand exceptional performance in extreme heat and corrosive settings. The company has built a solid reputation for its precision manufacturing, commitment to international quality standards, and the delivery of reliable, long-lasting solutions. Inconel 600 Buttweld Fittings find their place in various sectors, including chemical processing, marine, aerospace, oil and gas, and power generation, thanks to their remarkable resistance to oxidation, corrosion, and thermal stress. With state-of-the-art production facilities, rigorous quality control, and a focus on customer satisfaction, Teerasil Fittings and Plates guarantees safe and durable piping solutions for critical industrial applications around the globe.

Distributors of Inconel® 600 ASME SB366 Buttweld Reducer in Thailand, Inconel 600 Equal Tee Wholesaler Thailand, 600 Nickel Alloy Buttweld Tee Dealer Bangkok, Inconel Grade 600 Butt weld Pipe Fittings Stockists Pattaya, Alloy 600 Pipe Fittings Suppliers Chiang Mai, 600 Inconel Welded Pipe Fittings Suppliers Rayong, 600 Inconel Unequal Cross Exporters Nonthaburi, Nickelvac® 600 Pipe Fittings Bangkok, Thailand.

Inconel 600 Buttweld Fittings Specification

Specifications	ASTM B366 / ASME SB366
Dimension Standard	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
ASME B16.9	standard for – Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends.
ASME B16.28	standard for – Butt-Welded Short Radius Elbows & Returns Bends
MSS SP-43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Size Range	½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Seamless Butt Weld Fitting Size	1/2″ – 10″
Welded Butt Weld Fittings Size	1/2″ – 48″
Thickness	Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type	Seamless / Welded / Fabricated

Inconel 600 Buttweld Fittings are crafted from a nickel-chromium-iron alloy, consisting of about 72% nickel, 14–17% chromium, and 6–10% iron. This unique blend offers exceptional resistance to oxidation, carburization, and chloride-ion stress corrosion cracking, all while maintaining impressive strength and ductility across a wide temperature range. The alloy is known for its excellent metallurgical stability, mechanical integrity, and resistance to scaling and thermal fatigue, even in the harshest operating conditions. Its combination of tensile, yield, and creep strength ensures dependable performance in piping systems that face high temperatures, pressures, and aggressive chemical environments.

Inconel 600 Buttweld Fittings Chemical Composition

Grade		C	Mn	Si	Fe	S	Cr	Cu	Ni
600	min.	–	–	–	6.0	–	14.0	–	72.0
600	max.	0.15	1.0	0.5	10.0	0.015	17.0	0.5	–

Inconel 600 Buttweld Fittings Equivalent Grade

Grade	UNS No	Old British		Euronorm		GOST	Japanese JIS
		BS	En	No	AFNOR
Inconel 600	N06600	NA 13	NiCr15Fe	2.4816	NC15FE11M	МНЖМц 28-2,5-1,5	NCF 600

UNS N06600 Inconel® Alloy Butt weld Seamless Pipe Fitting In Thailand, Inconel Pipe Fittings Thailand, ASTM B366 Inconel 600 Pipe Elbow Bangkok, Inconel® Alloy 600 Buttweld Fittings Pattaya, Inconel Alloy Butt weld Pipe Fittings Chiang Mai, 600 Inconel® 45°/90°/180° Butt weld Elbow Rayong, 600 Nickel Alloy ANSI B16.9 Short & Long Radius Elbow Nonthaburi, ASME B16.28 600 Inconel® Alloy Butt weld Reducing Tee Bangkok, Thailand.

Largest Inconel 600 Buttweld Fittings Supplier in Bangkok, Thailand

Teerasil Fittings is a leading supplier of Inconel 600 Buttweld Fittings in Bangkok, Thailand. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Inconel 600 Buttweld Fittings Dimensions Standard

NOMINAL PIPE SIZE	ALL FITTINGS	ALL FITTINGS	ELBOWS AND TEES	180 DEG RETURN BENDS	180 DEG RETURN BENDS	180 DEG RETURN BENDS	REDUCERS	CAPS
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Centre -to- End Dimension A, B, C, M	Centre-to- Centre O	Back-to- Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	0.19	…	…	…	0.19	0.38

Steel Buttweld Fittings Pressure Rating Chart

NPS (inch)	Pipe Sch.	Wall Thk. (in)	OD (inch)	Temperature
				100	200	300	400	500
				Allowable Stress (Pressure Rating)
				16700	16700	16700	15500	14400
1″	40	0.133	1.315	2205	2205	2205	2047	1902
	80	0.179	1.315	3061	3061	3061	2841	2640
	160	0.250	1.315	4493	4493	4493	4170	3874
1 1/2″	40	0.145	1.900	1629	1629	1629	1512	1404
	80	0.200	1.900	2303	2303	2303	2138	1986
	160	0.281	1.900	3362	3362	3362	3120	2899
2″	40	0.154	2.375	1371	1371	1371	1272	1182
	80	0.218	2.375	1985	1985	1985	1843	1712
	160	0.344	2.375	3283	3283	3283	3047	2831
3″	40	0.216	3.500	1301	1301	1301	1208	1122
	80	0.300	3.500	1844	1844	1844	1712	1590
	160	0.438	3.500	2787	2787	2787	2587	2403
4″	40	0.237	4.500	1102	1102	1102	1023	950
	80	0.337	4.500	1596	1596	1596	1482	1377
	160	0.531	4.500	2611	2611	2611	2424	2552
5″	40	0.258	5.563	965	965	965	896	832
	80	0.375	5.563	1428	1428	1428	1325	1231
	160	0.625	5.563	2474	2474	2474	2296	2133
6″	40	0.280	6.625	877	877	877	814	756
	80	0.432	6.625	1379	1379	1379	1280	1189
	160	0.719	6.625	2382	2382	2382	2211	2054
8″	40	0.322	8.625	771	771	771	716	665
	80	0.500	8.625	1218	1218	1218	1131	1050
	160	0.906	8.625	2298	2298	2298	2133	1982
10″	40	0.365	10.750	699	699	699	649	603
	80	0.594	10.750	1159	1159	1159	1075	999
	160	1.125	10.750	2289	2289	2289	2124	1974

Why Choose Inconel 600 Buttweld Fittings from Teerasil Fittings?

Inconel 600 Buttweld Fittings from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Ferrochronin® 600 Pipe Fittings In Thailand, 600 Inconel® Concentric Reducer Thailand, Alloy 600 MSS-SP-43 Buttweld Swage Nipple Bangkok, MSS SP-79 Inconel 600 End Pipe Cap Suppliers Pattaya, Inconel® JIS NCF 600 Stub Ends Exporters Chiang Mai, Werkstoff No 2.4816 Inconel® Alloy Butt weld Eccentric Reducer Traders Rayong, Inconel 600 Buttweld Fittings Nonthaburi.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Inconel 600 Buttweld Fittings offer numerous advantages, including exceptional resistance to oxidation, carburization, and high-temperature corrosion, making them ideal for extreme environments. They provide excellent strength and stability at elevated temperatures, up to 2000°F (1093°C), ensuring reliable performance. The alloy’s high nickel content enhances its resistance to stress corrosion cracking and chloride-induced corrosion. Additionally, Inconel 600 fittings are highly durable, with superior weldability and fabricability, making them suitable for critical applications in industries like aerospace, chemical processing, and power generation. Their longevity and reliability reduce maintenance costs and downtime.

Types of Inconel 600 Buttweld Fittings

Are Custom Sizes Available for Inconel 600 Buttweld Fittings?

Yes, custom sizes for Inconel 600 Buttweld Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.

UNS N06600 Inconel® Alloy Butt weld Seamless Pipe Fitting In Thailand, Inconel Pipe Fittings Thailand, ASTM B366 Inconel 600 Pipe Elbow Bangkok, Inconel® Alloy 600 Buttweld Fittings Pattaya, Inconel Alloy Butt weld Pipe Fittings Chiang Mai, 600 Inconel® 45°/90°/180° Butt weld Elbow Rayong, 600 Nickel Alloy ANSI B16.9 Short & Long Radius Elbow Nonthaburi, ASME B16.28 600 Inconel® Alloy Butt weld Reducing Tee Bangkok, Thailand.

Application Industry of Inconel 600 Buttweld Fittings

These fittings are commonly found in heat exchangers, furnace components, gas turbine systems, chemical processing plants, and marine applications. In the aerospace sector, they are utilized in engine components and exhaust systems that endure high temperatures and corrosive gases. The oil and gas industry relies on them for offshore platforms, valves, and high-pressure piping systems, while power generation facilities incorporate them in steam lines and other critical applications.
