Hastelloy Forged Fittings

Teerasil Fittings is a leading manufacturer and supplier of high-quality fittings based in Bangkok, Thailand. Specializing in a wide range of industrial applications, we provide precision-engineered solutions to meet the demands of various sectors. Our product portfolio includes Hastelloy forged fittings, renowned for their exceptional corrosion resistance, strength, and durability in extreme environments. Whether for chemical processing, aerospace, or other critical industries, Teerasil Fittings ensures reliability and performance in every product we deliver.

Werkstoff No. 2.4617 Hastelloy High Pressure Forged Fittings Thailand, Manufacturer Of ASTM B564 C276 Hastelloy Bushing Thailand, Hastelloy ASTM B564 B2 Cross Bangkok, Hastelloy C22 Equal Tee Pattaya, X Hastelloy Full Couplings Chiang Mai, BS 3799 Union Rayong, Alloy C4 Forged 90 Deg Screwed Threaded Elbow in Nonthaburi.

Hastelloy Forged Fittings Specification

Specifications	ASTM B564 & ASME SB564
Standard	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size	1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Grades	Hastelloy C276, C22, C4, C2000, B2, B3, X Forged Fittings
Type	Socketweld Fittings, Screwed-Threaded Fittings
Class	2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Hastelloy forged fittings are made from high-performance alloys, primarily composed of nickel, molybdenum, and chromium, with small amounts of iron, tungsten, and cobalt. This composition offers exceptional resistance to corrosion, particularly in acidic and harsh environments. The mechanical properties include high tensile strength, excellent creep resistance, and resistance to pitting and stress-corrosion cracking. With a high melting point, these fittings maintain their strength even at elevated temperatures. Hastelloy forged fittings are ideal for applications in industries such as chemical processing, aerospace, and power generation.

Hastelloy Forged Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
B2	0.02 max	1.0 max	0.1 max	0.03 max	1.0 max	Bal	1.0 max	2.0 max	26 – 30	0.04 max

Hastelloy Forged Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy B2	9.2 g/cm3	1370 °C (2500 ºF )	Psi – 1,10,000 , MPa – 760	Psi – 51000 , MPa – 350	40 %

Hastelloy Forged Fittings Standards / Types And Pressure Class

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings Thailand, Hastelloy UNS N10276 Forged Pipe Fittings Thailand, Stockist of Alloy C22 Forged Elbow Bangkok, Hastelloy C276 Forged Fittings Pattaya, Hastelloy UNS N10665 Forged Fittings Chiang Mai, Global Supplier of Hastelloy B2 Socket weld Fittings Rayong, C2000 Hastelloy Threaded Fittings Dealer in Nonthaburi.

ASME SB564 Hastelloy Forged Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy B2	2.4617	N10665	–	–	–	–

Teerasil Fittings is a leading supplier of Hastelloy Forged Fittings in Bangkok, Thailand. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Hastelloy Forged Fittings from Teerasil Fittings?

Hastelloy Forged Fittings from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Best Price of B2 Hastelloy 3000 LB Forged Screwed Fittings Exporter In Thailand, DIN 2.4819 Hastelloy Alloy Street Elbow Thailand, Hastelloy Alloy DIN 2.4602 Forged Steel Fittings Bangkok, Stockholder Of Hastelloy UNS N06455 Threaded Plug Pattaya, Hastelloy UNS N06200 Socket Weld Cap Chiang Mai, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Rayong, C276 Hastelloy Alloy Pipe Nipple Traders in Nonthaburi.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy forged fittings offer several key advantages, making them ideal for demanding industrial applications. Their superior corrosion resistance, especially against acids, chlorine, and high-temperature environments, ensures long-lasting performance. These fittings also provide excellent strength, even in extreme conditions, and are resistant to stress corrosion cracking and pitting. With their ability to maintain mechanical properties at elevated temperatures, Hastelloy forged fittings are reliable in harsh chemical processing, aerospace, and power generation industries. Their durability and resilience reduce maintenance costs and improve the overall efficiency of critical systems.

Types of Hastelloy Forged Fittings

Are Custom Sizes Available for Hastelloy Forged Fittings?

Yes, custom sizes for Hastelloy Forged Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings Thailand, Hastelloy UNS N10276 Forged Pipe Fittings Thailand, Stockist of Alloy C22 Forged Elbow Bangkok, Hastelloy C276 Forged Fittings Pattaya, Hastelloy UNS N06200 Socket Weld Cap Chiang Mai, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Rayong, C276 Hastelloy Alloy Pipe Nipple Traders in Nonthaburi.

Application Industry of Hastelloy Forged Fittings

Hastelloy forged fittings are widely used in industries requiring high corrosion resistance and strength under extreme conditions. They are commonly applied in chemical processing, petrochemical, and pharmaceutical industries for handling corrosive fluids and gases. These fittings are also used in aerospace, marine, and power generation sectors due to their excellent performance in high-temperature environments. Hastelloy forged fittings are ideal for applications involving aggressive chemicals, acids, and high-pressure systems, ensuring reliability in critical systems like reactors, heat exchangers, and piping systems.
