Teerasil Fittings is a trusted manufacturer and supplier of premium pipe fittings based in Bangkok, Thailand. Specializing in Alloy Steel Forged Fittings, we provide high-strength, durable solutions for critical pipeline systems. Our alloy steel fittings are designed to withstand high-pressure environments, offering excellent corrosion resistance, impact toughness, and longevity. Ideal for industries such as oil, gas, petrochemical, and power generation, Teerasil Fittings ensures reliable, secure, and leak-proof connections, enhancing the performance and efficiency of your pipeline systems in demanding applications.
| Specifications | Alloy Steel |
|---|---|
| Size | 1/8” NB TO 48” NB. |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Type | Seamless / Welded / Fabricated |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
Alloy Steel Forged Fittings are primarily composed of carbon, manganese, phosphorus, sulfur, and silicon, with additional alloying elements such as chromium, molybdenum, nickel, and vanadium to enhance strength, toughness, and resistance to wear and corrosion. These fittings offer superior mechanical properties, including high tensile strength, typically ranging from 550 to 700 MPa, and excellent yield strength, often exceeding 400 MPa. They are designed to perform reliably in high-pressure, high-temperature environments, providing excellent impact resistance and durability, making them ideal for demanding applications in industries like oil, gas, and petrochemicals.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| Alloy Steel | 0.08 – 0.12 | 0.3 – 0.6 | 0.5 | 0.01 | 0.02 | 8.5 – 9.5 | 0.85 – 1.05 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| Alloy Steel | 415 | 585 | 20 |
Teerasil Fittings is a leading supplier of Alloy Steel Forged Fittings in Bangkok, Thailand. We offer an extensive range of Alloy Steel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel Forged Fittings from Teerasil Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel Forged Fittings offer numerous advantages, including exceptional strength and durability, making them ideal for high-pressure and high-temperature applications. The alloying elements, such as chromium, molybdenum, and nickel, enhance corrosion resistance and wear resistance, ensuring long-term performance even in harsh environments. These fittings are designed for superior impact toughness, reducing the risk of failure in critical systems. Their forged construction provides enhanced mechanical properties, offering leak-proof and secure connections. Alloy Steel Forged Fittings are perfect for industries like oil, gas, petrochemical, and power generation, providing reliable and cost-effective solutions.
Yes, custom sizes for Alloy Steel Forged Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com
| NPS | Outside diameter D | 45° Long Rad Center to End B | 90° Long Rad Center to End A | 45° 3D Center to End B | 90° 3D Center to End A |
| 1/2 | 21.03 | 16 | 38 | ||
| 3/4 | 26.07 | 19 | 38 | 24 | 57 |
| 1 | 33.04 | 22 | 38 | 31 | 76 |
| 1¼ | 42.02 | 25 | 48 | 39 | 95 |
| 1½ | 48.03 | 29 | 57 | 47 | 114 |
| 2 | 60.03 | 35 | 76 | 63 | 152 |
| 2½ | 73 | 44 | 95 | 79 | 190 |
| 3 | 88.09 | 51 | 114 | 95 | 229 |
| 3½ | 101.06 | 57 | 133 | 111 | 267 |
| 4 | 114.03 | 64 | 152 | 127 | 305 |
| 5 | 141.03 | 79 | 190 | 157 | 381 |
| 6 | 168.03 | 95 | 229 | 189 | 457 |
| 8 | 219.01 | 127 | 305 | 252 | 610 |
| 10 | 273 | 159 | 381 | 316 | 762 |
| 12 | 323.08 | 190 | 457 | 378 | 914 |
| 14 | 355.06 | 222 | 533 | 441 | 1067 |
| 16 | 406.04 | 254 | 610 | 505 | 1219 |
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Alloy Steel Forged Fittings are widely used in industries that require high-strength and durable pipeline systems. They are ideal for applications in oil and gas, petrochemical, power generation, and chemical processing industries, where high pressure, temperature, and corrosion resistance are essential. These fittings are commonly used in critical systems such as pipelines, valves, and flanges for secure and leak-proof connections. Alloy Steel Forged Fittings are also ideal for offshore drilling, water treatment plants, and power plants, providing long-lasting, reliable performance in demanding environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
