Teerasil Fittings and Plates, established in Bangkok, Thailand, is a prominent manufacturer and supplier of Stainless Steel 310/310S Buttweld Fittings. These fittings are greatly sought after due to their superior resistance to high temperatures, oxidation, and corrosion, positioning them as an optimum solution for high-performance materials in industries. Teerasil guarantees that their Stainless Steel 310/310S Buttweld Fittings are of the highest quality and have durability with outstanding performance even at the toughest conditions. With dedication to accuracy, Teerasil delivers reliable products that can last even under harsh environments across various industrial uses.
Specifications : ASTM A403 / ASME SA403
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Stainless Steel 310/310S is an austenitic alloy made of mostly chromium and nickel and provides excellent high-temperature oxidation and corrosion resistance. Stainless Steel 310 has more chromium and nickel content, which gives it better oxidation resistance, whereas 310S is a low carbon variant that reduces carbide precipitation when the material is welded, making it suitable for welded applications. The material has tensile strength of 520 MPa (75 ksi) and yield strength of 205 MPa (30 ksi) and is strong and resistant to high-temperature conditions. Its characteristic attributes make it especially useful in applications where heat and hostile chemical atmosphere resistance is needed.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | 0.75 max | 19.00 – 21.00 | 53.095 min |
| SS 310H | 0.04 – 0.10 | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | – | 19.00 – 21.00 | 53.885 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
Teerasil Fittings is a leading supplier of Stainless Steel 310 Buttweld Fittings in Bangkok, Thailand. We offer an extensive range of Stainless Steel 310S Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | SS 310 | SS 310S |
| WERKSTOFF NR. | 1.4841 | 1.4845 |
| UNS | S31000 | S31008 |
| JIS | SUS 310 | SUS 310S |
| BS | 310S24 | 310S16 |
| GOST | 20Ch25N20S2 | 20Ch23N18 |
| AFNOR | – | – |
| EN | X15CrNi25-20 | X8CrNi25-21 |
Stainless Steel 310 / 310S Buttweld Fittings from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless steel 310/310S Buttweld Fittings provide excellent high heat resistance, making them ideal for applications in heat exchangers, furnaces and boilers Their high chromium and nickel content ensures exceptional resistance resist corrosion and oxidation even in harsh environments. These materials retain strength and last longer at high temperatures, increasing reliability in extreme conditions. The low carbon content of 310S reduces carbide precipitation, improves weldability, and reduces susceptibility to intergranular corrosion. Their versatility and robust mechanical properties make them desirable in the industrial and chemical industries. Simple construction and low maintenance further enhance profitability.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
|---|---|---|---|---|---|---|---|---|
| (inches) | (mm) | (inches) | Length (inches) | Center to End (inches) | Center to End (inches) | Lap Diameter (inches) | Long Length (inches) | Short Length (inches) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Yes, custom sizes for Stainless Steel 310 / 310S Buttweld Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.
Stainless Steel 310/310S Buttweld Fittings are normally employed in corrosive and high-temperature applications, especially in petrochemical, power generation, and aerospace industries. These fittings are extensively applied in furnace, heat exchangers, gas turbines, and exhaust applications, where they can withstand up to 1100°C (2012°F) temperatures. They are also well-suited for the chemical and food processing industries, where they offer the kind of resistance to corrosion and intense heat that is needed. The fittings are also employed in exhausts and other high-stress applications where their enhanced properties provide long-term reliability and endurance.
