Phanuphong Steel stands out as a trusted manufacturer and supplier of Stainless Steel 304 Buttweld Fittings right in the heart of Bangkok, Thailand. We pride ourselves on delivering top-notch piping solutions that cater to a variety of industries. Stainless Steel 304 is the go-to choice for many, thanks to its remarkable corrosion resistance, durability, and cost-effectiveness. Our buttweld fittings are crafted to ensure smooth flow, leak-proof connections, and long-lasting performance, making them perfect for critical piping systems. With a strong focus on quality control, competitive pricing, and timely delivery, Phanuphong Steel serves sectors like chemical processing, food & beverage, pharmaceuticals, oil & gas, and power generation.
| Specifications | ASTM A403 / ASME SA403 |
|---|---|
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | Seamless / Welded / Fabricated |
These Stainless Steel 304 Buttweld Fittings are made up of 18–20% chromium and 8–10.5% nickel, along with low carbon content that boosts their corrosion resistance and weldability. This unique composition offers outstanding resistance to oxidation and intergranular corrosion across various environments. With a tensile strength of around 515 MPa, yield strength of 205 MPa, and an elongation of 40%, these fittings are built to last while maintaining flexibility. Their impressive mechanical properties, along with good formability and toughness even in cryogenic conditions, make Stainless Steel 304 buttweld fittings a versatile and dependable option for numerous industrial applications.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
| 304L | min. | – | – | – | – | – | 18.0 | – | 8.0 | – |
| max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 12.0 | 0.10 | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
Teerasil Fittings is a leading supplier of Stainless Steel 304 Buttweld Fittings in Bangkok, Thailand. We offer an extensive range of Stainless Steel 304 Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
|---|---|---|---|---|---|---|---|
| BS | En | No | Name | ||||
| 304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
| 304L | S30403 | 304S11 | 58E | 1.4306/1.4307 | X2CrNi18-9 / X2CrNi19-11 | 2332 | SUS 304L |
Stainless Steel 304 Buttweld Fittings from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Stainless steel 304 buttweld fittings provide excellent corrosion resistance, making them ideal for a variety of environments including marine and chemical applications Their long-lasting strength ensures long service life, and reduces replacement costs. These fittings have excellent weldability, providing easy and reliable installation. With great strength and strength, they withstand changes in pressure and temperature well. Their smooth interior reduces friction losses and increases flow efficiency in piping systems. Also, SS 304 is cost-effective compared to high-quality alloys while maintaining a luxurious appearance. These advantages make SS 304 buttweld fittings versatile for a variety of applications.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
|---|---|---|---|---|---|---|---|---|
| (inches) | (mm) | (inches) | Length (inches) | Center to End (inches) | Center to End (inches) | Lap Diameter (inches) | Long Length (inches) | Short Length (inches) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Yes, custom sizes for Stainless Steel 304 Buttweld Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.
You’ll find Stainless Steel 304 Buttweld Fittings being utilized across many industries, thanks to their strength, corrosion resistance, and hygienic qualities. They’re a common sight in food and beverage processing plants, breweries, and dairies, where their ability to resist contamination and endure cleaning chemicals is crucial. In the pharmaceutical and chemical sectors, they’re essential for piping systems that transport corrosive fluids and gases. Additionally, they’re used in oil refineries, power plants, water treatment facilities, and marine environments. With their excellent weldability, durability, and smooth internal finish, these fittings guarantee efficient flow and reduced maintenance needs.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
