Teerasil Fittings is a trusted manufacturer and supplier based in Bangkok, Thailand. It specializes in high-quality pipe fittings, including Equal, Reducing, and Split Tees. These fittings are tailored to meet the needs of industries such as oil and gas, chemical processing, and construction. Our Equal Tees connect pipes of the same diameter, while our Reducing Tees facilitate smooth transitions between pipe sizes. Additionally, our Split Tees offer quick and easy installation for retrofitting and maintenance projects, ensuring superior performance, durability, and reliability across various applications.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe Tee Size: 1/2″~24″
ERW / Welded / Fabricated Pipe Tee Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: Pipe Tee, Equal Tee, Fitting Tee, Butt weld Tee
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Reducing Tee Size: 1/2″~24″
ERW / Welded / Fabricated Reducing Tee Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: Unqual Tee, Reducing Tee
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Size: 2″~36″ 15-1200
Pressure 150#~2500#
Wall Thickness : Sch 10- Sch160
Material : Stainless Steel, Carbon Steel, Alloy Steel, Monel, Hastelloy, Inconel, Incoloy, Nickel Alloy, Copper Nickel, Super Duplex Steel, Super Duplex Steel, Titanium
Form: Split Tees
Tee fittings are typically made from materials like stainless steel, carbon steel, and alloy steel, with compositions including iron, chromium, nickel, and molybdenum. They offer high tensile strength, corrosion resistance, and excellent weldability. The mechanical properties of tee fittings ensure they can withstand high pressure, temperature variations, and mechanical stresses. These fittings are designed to provide durable and reliable connections in piping systems, ensuring optimal flow and system integrity.
Teerasil Fittings is a leading supplier of Tee Fittings in Bangkok, Thailand. We offer an extensive range of Equal/ Reducing/ Split Tee, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Equal/ Reducing/ Split Tee from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
A tee is a versatile pipe fitting that connects three pipe sections, creating a branching point for fluid or gas flow. It is designed to ensure smooth flow, minimize resistance, and distribute pressure effectively. Tees are available in various materials and sizes, offering durability, corrosion resistance, and ease of installation. They provide a reliable solution for creating branch connections, enabling the efficient flow of liquids or gases through piping systems.
| Nominal Pipe Size | Outside diameter at bevel | Center-to-End | |
|---|---|---|---|
| Run (C) | Outlet(M) | ||
| 1/2″ | 21.3 | 25 | 25 |
| 3/4″ | 26.7 | 29 | 29 |
| 1″ | 33.4 | 38 | 38 |
| 1 1/4″ | 42.2 | 48 | 48 |
| 1 1/2″ | 48.3 | 57 | 57 |
| 2″ | 60.3 | 64 | 64 |
| 2 1/2″ | 73.0 | 76 | 76 |
| 3″ | 88.9 | 86 | 86 |
| 3 1/2″ | 101.6 | 95 | 95 |
| 4″ | 114.3 | 105 | 105 |
| 5″ | 141.3 | 124 | 124 |
| 6″ | 168.3 | 143 | 143 |
| 8″ | 219.1 | 178 | 178 |
| 10″ | 273.0 | 216 | 216 |
| 12″ | 323.8 | 254 | 254 |
| 14″ | 355.6 | 279 | 279 |
| 16″ | 406.4 | 305 | 305 |
| 18″ | 457.0 | 343 | 343 |
| 20″ | 508.0 | 381 | 381 |
| 22″ | 559.0 | 419 | 419 |
| 24″ | 610.0 | 432 | 432 |
| Nominal Pipe Size | Outside diameter at bevel | Center-to-End | |||
|---|---|---|---|---|---|
| Run | Outlet | Run | Outlet | Run (C) | Outlet (M) |
|
1/2″ |
1/4″
3/8″ |
21.3 |
13.7
17.3 |
25 |
25 |
|
3/4″ |
3/8″
1/2″ |
26.7 |
17.3
21.3 |
29 |
29 |
|
1″ |
1/2″
3/4″ |
33.4 |
21.3
26.7 |
38 |
38 |
|
1 1/4″ |
1/2″
3/4″
1″ |
42.2 |
21.3
26.7
33.4 |
48 |
48 |
|
1 1/2″ |
1/2″
3/4″
1″
1 1/4″ |
48.3 |
21.3
26.7
33.4
42.2 |
57 |
57 |
|
2″ |
3/4″
1″
1 1/4″
1 1/2″ |
60.3 |
26.7
33.4
42.2
48.3 |
64 |
44
51
57
60 |
|
2 1/2″ |
1″
1 1/4″
1 1/2″
2″ |
73.0 |
33.4
42.2
48.3
60.3 |
76 |
57
64
67
70 |
|
3″ |
1 1/4″
1 1/2″
2″
2 1/2″ |
88.9 |
42.2
48.3
60.3
73.0 |
86 |
70
73
76
83 |
|
3 1/2″ |
1 1/2″
2″
2 1/2″
3″ |
101.6 |
48.3
60.3
73.0
88.9 |
95 |
79
83
89
92 |
|
4″ |
1 1/2″
2″
2 1/2″
3″
3 1/2″ |
114.3 |
48.3
60.3
73.0
88.9
101.6 |
105 |
86
89
95
98
102 |
|
5″ |
2″
2 1/2″
3″
3 1/2″
4″ |
141.3 |
60.3
73.0
88.9
101.6
114.3 |
124 |
105
108
111
114
117 |
|
6″ |
2 1/2″
3″
3 1/2″
4″
5 |
168.3 |
73.0
88.9
101.6
114.3
141.3 |
143 |
121
124
127
130
137 |
|
8″ |
3 1/2″
4″
5″
6″ |
219.1 |
101.6
114.3
141.3
168.3 |
178 |
152
156
162
168 |
|
10″ |
4″
5″
6″
8″ |
273.0 |
114.3
141.3
168.3
219.1 |
216 |
184
191
194
203 |
|
12″ |
5″
6″
8″
10″ |
323.8 |
141.3
168.3
219.1
273.0 |
254 |
216
219
229
241 |
|
14″ |
6″
8″
10″
12″ |
355.6 |
168.3
219.1
273.0
323.8 |
279 |
238
248
257
270 |
|
16″ |
6″
8″
10″
12″
14″ |
406.4 |
168.3
219.1
273.0
323.8
355.6 |
305 |
264
273
283
295
305 |
|
18″ |
8″
10″
12″
14″
16″ |
457.0 |
219.1
273.0
323.8
355.6
406.4 |
343 |
298
308
321
330
330 |
|
20″ |
8″
10″
12″
14″
16″
18″ |
508.0 |
219.1
273.0
323.8
355.6
406.4
457.0 |
381 |
324
333
346
356
356
368 |
|
22″ |
10″
12″
14″
16″
18″
20″ |
559.0 |
273.0
323.8
355.6
406.4
457.0
508.0 |
419 |
359
371
381
381
394
406 |
|
24″ |
10″
12″
14″
16″
18″
20″
22″ |
610.0 |
273.0
323.8
355.6
406.4
457.0
508.0
559.0 |
432 |
384
397
406
406
419
432
432 |
Yes, custom sizes for Equal/ Reducing/ Split Tee are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.
Tee fittings are commonly used in plumbing, piping, and industrial systems to create branches in a pipeline. They allow the flow of fluids or gases to split or combine at specific points, ensuring efficient distribution or redirection. Tee fittings are essential in various applications such as water supply, HVAC systems, and chemical processing plants. They are designed to offer a reliable and leak-proof connection, making them ideal for residential and industrial applications requiring precise flow control and distribution.
