Carbon Steel A105 Forged Fittings

Teerasil Fittings is a trusted manufacturer and supplier of high-quality piping components based in Bangkok, Thailand. Renowned for precision and durability, we specialize in Carbon Steel A105 Forged Fittings, designed to meet the rigorous demands of industrial applications. Our fittings are crafted for superior performance in high-pressure and high-temperature environments, ensuring reliability in diverse sectors like oil and gas, petrochemicals, and power plants. With a commitment to excellence, Teerasil Fittings delivers innovative solutions tailored to your piping needs.

Carbon A105 Forged Fittings In Thailand, Carbon Steel A105 High Pressure Forged Fittings Bangkok, Carbon Steel A105 Threaded Fittings Pattaya, Carbon Steel A105 Socket weld Fittings Chiang Mai, CS Forged Fittings Rayong, Carbon Steel A105 Forged Fittings Nonthaburi, Carbon Steel A105 Socket weld Fittings In Thailand, Carbon Steel ASTM A105 Threaded Fittings Manufacturer in Bangkok, Thailand.

Carbon Steel A105 Forged Fittings Specification

Forged Fittings Specifications	ASTM A105/ ASME SA105
Carbon Steel A105 Forged Fittings size	1/8” NB to 4” NB (Socket weld & Screwed-Threaded)
Carbon Steel A105 Forged Fittings Dimensions	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Carbon Steel A105 Forged Fittings Types	Socketweld Fittings, Screwed-Threaded Fittings
ASTM A105 Carbon Steel A105 Forged Fittings Pressure Rating	Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs
Carbon Steel A105 Forged Fittings Thread	NPT, BSPT, BSPP
Carbon Steel A105 Forged Fittings Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Carbon A105 Forged Fittings Origin & Mills	Japanese, Indian, USA, Korean, European, Ukraine, Russian
Specialized manufacturer of	90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs

Chemical Composition of Carbon Steel A105 Buttweld Fittings

Grade	C	Si	Mn	P	S	Mo	Ni	Cr	Cu	V
A105	0.35	0.10–0.35	0.60–1.05	0.035	0.040	0.12	0.40	0.30	0.40	0.08

Mechanical Properties of Carbon Steel A105 Butt weld Pipe Fittings

Grade	Yield Strength, Min (MPa)	Tensile Strength, Min (MPa)	Elongation, min, %
A105	250	485	30

Carbon Steel A105 Forged Fittings are primarily composed of carbon (0.35% max), manganese (0.60-1.05%), phosphorus (0.035% max), sulfur (0.040% max), and silicon (0.10-0.35%). These elements ensure strength, durability, and machinability. They offer excellent mechanical performance, with a minimum tensile strength of 485 MPa, yield strength of 250 MPa, and elongation of 22%. Their hardness typically measures at 187 HBW max. These properties make A105 forged fittings ideal for high-pressure and high-temperature applications in various industries.

Manufacturing Standards of Carbon Steel A105 Forged Fittings

ASTM A105 / A105M	Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel A105 Forged Fittings
BS21	Threading.
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ISO 4144	Carbon Steel A105 fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs

Competitive Price of Carbon Steel A105 Forged Tees Thailand, Ready Stock of Carbon Steel A105 Forged Elbow Thailand, CS A105 Forged Cross Trader Bangkok, Carbon Steel A105 Coupling Pattaya, Largest Stockholder of Carbon A105 Forged Fittings in Chiang Mai, ASTM A105 Socket weld Fittings Manufacturers in Rayong, Carbon Steel A105 Forged Fittings Nonthaburi.

Carbon Steel A105 Forged Fittings Forms & Availability

Products		Size
ASTM A105 Carbon Steel 90° Elbow	ASTM A105 Carbon Steel 45° Elbow	Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
ASTM A105 Carbon Steel Forged Tee	ASTM A105 Carbon Steel Union
ASTM A105 Carbon Steel Forged Cross	ASTM A105 Carbon Steel Insert
ASTM A105 Carbon Steel Screwed Bushing	ASTM A105 Carbon Steel Threaded Pipe Nipple
ASTM A105 Carbon Steel Forged Socket weld Cap	ASTM A105 Carbon Steel Screwed Coupling
ASTM A105 Carbon Steel Forged Plug	ASTM A105 Carbon Steel Street Elbow

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Carbon Steel A105 Forged Fittings offer several advantages, making them ideal for industrial applications. They provide excellent strength and durability, ensuring long service life under high-pressure and high-temperature conditions. Their corrosion resistance makes them suitable for harsh environments, including oil, gas, and chemical industries. With exceptional machinability and weldability, they are easy to install and maintain. These fittings deliver cost-effective performance due to their affordability and extended reliability. Additionally, they comply with international standards, ensuring safety, quality, and compatibility with various piping systems.

Why Choose Carbon Steel A105 Forged Fittings from Teerasil Fittings?

Carbon Steel A105 Forged Fittings from Teerasil Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Carbon Steel A105 Threaded Fittings Dealer In Thailand, Buy Carbon Steel A105 Full Coupling Thailand, ASME SA105 Forged Bushing Bangkok, ANSI B16.11 CS A105 Forged Plugs Pattaya, Carbon A105 Forged Cap Chiang Mai, CS ASTM A105 Forged Socket weld Fittings Stockist Rayong, Carbon Steel A105 Threaded Nipple Wholesaler Nonthaburi, Carbon A105 Half Coupling In Thailand, Carbon Steel A105 Forged Union Thailand, Carbon Steel A105 Welding Boss Bangkok, Carbon Steel A105 Industrial Forged Fittings Supplier in Bangkok, Thailand.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Carbon Steel A105 Forged Fittings

Are Custom Sizes Available for Carbon Steel A105 Forged Fittings?

Yes, custom sizes for Carbon Steel A105 Forged Fittings are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.

Carbon A105 Forged Fittings In Thailand, Carbon Steel A105 High Pressure Forged Fittings Bangkok, Carbon Steel A105 Threaded Fittings Pattaya, Carbon Steel A105 Socket weld Fittings Chiang Mai, CS Forged Fittings Rayong, Carbon Steel A105 Forged Fittings Nonthaburi, Carbon Steel A105 Socket weld Fittings In Thailand, Carbon Steel ASTM A105 Threaded Fittings Manufacturer in Bangkok, Thailand.

Application Industry of Carbon Steel A105 Forged Fittings

Carbon Steel A105 Forged Fittings are widely used in industries requiring robust and reliable piping solutions. They are essential in oil and gas processing, petrochemical plants, power generation, and refineries, where high-pressure and high-temperature operations are standard. These fittings are also employed in shipbuilding, construction, and water treatment systems. Their strength and corrosion resistance make them suitable for handling steam, water, gas, and other fluids. With compatibility across various piping systems, they ensure seamless operations in both industrial and commercial applications.
