Teerasil Fittings, based in Bangkok, Thailand, is a trusted manufacturer and supplier of high-quality industrial fittings designed to meet diverse piping needs. Our 90° Short Radius Elbows are crafted to provide quick directional changes in compact piping systems, ideal for installations with limited space. These elbows are made from durable materials like stainless steel and alloys, ensuring long-lasting performance. Widely used in industries such as oil and gas, chemical processing, and HVAC, Teerasil Fittings delivers reliable solutions for optimized flow and system efficiency.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe 90° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Short Radius Elbow
90° Short Radius Elbows are typically made from durable materials like stainless steel, carbon steel, and alloys such as Duplex and Super Duplex, depending on the application requirements. These materials provide high tensile strength (500-900 MPa), yield strength (250-700 MPa), and elongation (20-30%), making them suitable for high-pressure and high-temperature environments. The short radius design ensures quick directional changes in compact spaces while maintaining adequate flow. These elbows offer excellent corrosion resistance, mechanical reliability, and are ideal for industries like oil and gas, chemical processing, and HVAC systems.
Stainless Steel 90° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Teerasil Fittings is a leading supplier of 90 Deg Short Redius Elbow in Bangkok, Thailand. We offer an extensive range of 90 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Short Redius Elbow from Teerasil Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Short Radius Elbows provide several key advantages, including their ability to fit into compact spaces where standard long radius elbows may not be suitable. Their design allows for quick directional changes in piping systems, making them ideal for installations with limited room. Despite their tighter bend, these elbows offer reliable flow control and minimal pressure loss in low-velocity systems. Made from durable materials like stainless steel and alloys, they offer corrosion resistance and long-lasting performance. Widely used in industries such as HVAC, chemical processing, and plumbing, they ensure efficient and effective flow management.
Yes, custom sizes for 90 Deg Short Redius Elbow are available at Teerasil Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@teerasilfittings.com.
| NPS | O.D. D | Center-to-End A |
| 1 | 33.4 | 25 |
| 1 ¼ | 42.2 | 32 |
| 1½ | 48.3 | 38 |
| 2 | 60.3 | 51 |
| 2 ½ | 73 | 64 |
| 3 | 88.9 | 76 |
| 3 ½ | 101.6 | 89 |
| 4 | 114.3 | 102 |
| 5 | 141.3 | 127 |
| 6 | 168.3 | 152 |
| 8 | 219.1 | 203 |
| 10 | 273 | 254 |
| 12 | 323.8 | 305 |
| 14 | 355.6 | 356 |
| 16 | 406.4 | 406 |
| 18 | 457 | 457 |
| 20 | 508 | 508 |
| 22 | 559 | 559 |
| 24 | 610 | 610 |
90° Short Radius Elbows are commonly used in compact piping systems where space is limited. These elbows are ideal for applications in industries such as HVAC, plumbing, and chemical processing, where quick directional changes are needed within confined areas. They are also utilized in smaller-scale industrial setups, fuel lines, and water distribution systems. While providing efficient flow control, they help maintain optimal system performance in tight spaces, offering durability and resistance to corrosion, high pressures, and temperatures in various operational conditions.
